QUART DVT_150圖像質量模體，QUART DVT_150模體

QUART DVT_150 3D圖象質量測試模體

QUART DVT_150模體專為數字體層析成像（DVT）3D X射線裝置的質量控制而設計。

QUART DVT_150圖像質量模體，QUART DVT_150模體功能的對象來測試空間分辨率DVT，耳鼻喉科和C臂X射線設備的3D模式。

QUART DVT_150圖像質量模體，QUART DVT_150模體符合DIN 6868-150。

QUART DVT_150圖像質量模體，QUART DVT_150模體技術規格
空間分辨率：7個圓柱形物體
對象特征：在10mm PMMA片材中的Ø0.5 / 0.6 / 0.7 / 0.8 / 0.9 / 1 / 1.3mm
尺寸：120 x 120 x 60毫米




QUART DVT_150
3D Image Quality Test Phantom

The QUART DVT_150 phantom is designed for quality control of Digital Volume Tomography (DVT) 3D x-ray installations.

Phantom features objects to test spatial resolution of DVT, ENT and C-arm x-ray equipment featuring 3D modality.

The phantom complies with DIN 6868-150.

Technical Specifications
SPATIAL RESOLUTION: 7 cylindrical objects
OBJECT FEATURES: Ø 0.5/0.6/0.7/0.8/0.9/1/1.3 mm in a 10 mm PMMA sheet
SIZE: 120 x 120 x 60 mm
